Three-stage ESS profile
Each stage runs in order. The second vibration run confirms the part survived thermal cycling.
-
Pre random vibration
20 to 2000 Hz profile, 5 minutes on each of the X, Y and Z axes.
-
Thermal cycling
One hour at −40 °C and one hour at +71 °C, ramping at 10 °C/min or faster, for 10 cycles.
-
Post random vibration
The vibration profile is repeated to confirm the part survived cycling.
Standards we test and build to
Standards vary by product family. Each datasheet lists the ones that apply.
- MIL-STD-810GEnvironmental qualification for modules
- MIL-STD-461EEMI and EMC specification
- MIL-STD-202Test methods for cables and connectors
- MIL-HDBK-241BEMI reduction guidelines for power supplies
- EN 55011 / EN 61326EMC for rack equipment
- Hi-Pot testingCore-to-braid breakdown on NDT cable assemblies
- RoHSCompliant antenna range
Also supplied: Times Microwave LMR® tool kits (TK-400/400-75EZ-HC), TF-047 micro-coaxial cable and StripFlex® 393 assemblies.
Need a part that is not in the catalogue?
Every product can be customised for length, connector, power or frequency. Share your requirement and we reply with availability, lead time and a datasheet.
